Healthcare Safety Kit

What’s in the box

2x Portal Beam

A 9-in-1 cloud-enabled thermal camera sensor for Occupancy, Environmental Monitoring, Wayfinding, Contact Tracing and more using Bluetooth LE technology.

3x Smart Badge

A 2-button personnel, access control badge holder for Contact Tracing, Staff Duress and Safety Evacuation applications.

2x Portal Light

A plug-and-play Bluetooth Gateway that allows you to connect the Portal Beam to the existing WiFi network in less than one minute.

2x Asset Tag 2

Lorem ipsum lorem lorem, lorem ipsum lorem lorem, lorem ipsum lorem lorem, orem ipsum lorem lorem, orem ipsum lorem lorem.

1 Year Kio Cloud Access

Visualize and store all room- and space-related occupancy, location and sensor information from the Portal Beam in the Cloud.
See the location of people on a map.
Get historical and real-time insights.
Set-up alerts and notifications for threshold changes in occupancy, temperature, air quality or contact tracing.
Consume all data and integrate into your applications via a rich EventAPI.

Tech specs

Portal Beam
Smart Badge
Portal Light AC US (EU, UK, AUS plugs also available)

Electronics
- Microcontroller Nordic Semiconductor nRF52832
- IR beam (4-directional LEDs)
- Environmental sensing tracking temperature, relative humidity, light, atmospheric pressure, room air quality, particle density
- Occupancy sensing
- Far-Infrared wide-angle thermal camera
Sensors
- Temperature Operating range: -40°C to +85°C Typical accuracy: +/- 1°C
- Relative Humidity Operating range: 0-100% Typical accuracy: 20‒80 % r.H., +25°C
- Air Quality Index Range: 0 - 255
- Pressure Operating range: 300-1100 hPa Typical accuracy: 0.6 hPa
- Light Sensor Operating range: 1-100%
Features
- Over-the-Air update/cloud management
- RGB LEDs signaling device state
- IR beaconing for room level tracing
- Visual/sound alerts
- Beacon broadcasting
- Environmental sensing Humidity, temperature, atmospheric pressure, air quality
Connectivity
- Bluetooth Bluetooth Low Energy 5.0
- Range Up to 50 meters
Power
- Option 1: Input Voltage DC 6V-24V barrel type terminal
- Option 2: Batteries 6x ER14505 (15.6 Ah), DC 3.6V
Environmental Requirements
- Operation Temperature +18°C / +25°C (+64.4F / +77F)
- Operation Humidity 10%~90% - non condensing
- Operating Conditions Do not expose to strong light. Do not use in proximity of head and cold sources.
Physical Specification
- Height 7 in | 18 cm
- Width 7 in | 18 cm
- Depth 1.8 in | 4.6 cm
Mounting
- Dedicated mounting plate
- Optional mounting bracket available separately
Beacon standards compatibility
- iBeacon Yes
- Eddystone Yes
- Kontakt.io Location Yes
- Kontakt.io Secure Profile Yes
- Telemetry BLE fingerprinting, air quality, temperature 16 bits, humidity, pressure, light level, occupancy
Warranty
- 1 Year
Product identification
- QR Code yes, unique ID
- MAC yes, printed

Portal Beam Tech Spec (PDF)

Portal Beam Setup Guide (PDF)

Electronics
- Microcontroller nRF52832
- IR receiver
- LIS2DH/LIS3DH accelerometer (motion and orientation detection)
- 2 buttons
Connectivity
- Bluetooth Low Energy 5.0
- Up to 30 meters
Battery
- Model CP224147
- Battery life 3 years with IR active, 5 years 1 Hz beaconing
- Replaceable No
Environmental Requirements
- Operation temperature 0°C ~ 55°C
- Operation humidity 10% ~ 90% - non condensing
Battery/Mains Operating Mode
- Over-the-Air beacon update/Cloud management
- Beacon broadcasting
- Motion detection
- User buttons

Smart Badge Tech Spec (PDF)

Electronics
- Microcontroller ESP32
Physical Specification
- Dimensions Dimensions: 110 x 62.3 x 34.9 mm
- Push button
- RGB LED
Power
- Input voltage 110VAC
- Output voltage 110V
- Max load current 16A
- Max load 3520W
- Plug type US
Connectivity
- WiFi 802.11 b/g/n (802.11n up to 150 Mbps) 2.4 GHz ~ 2.5 GHz
- Bluetooth Bluetooth v4.2 BR/EDR and BLE specification
- Range Up to 50 meters
Environmental Requirements
- Operation temperature 0°C~40°C
- Operation humidity 10%~90% - non condensing
Features
- WiFi connectivity with open/WEP/WPA/WPA2_PSK
- Over-the-Air gateway firmware update
- WiFi fallback mode (secondary WiFi configuration)
- Configuration via WiFi or mobile application
- RGB LEDs signaling device state

Portal Light Plug US Tech Spec (PDF)

Portal Light Plug EU Tech Spec (PDF)
